DT-7101E(H) HD Portable Digital image wireless tra
Wendy Wang
Contact person
Basic Information
HD Portable Digital image wireless transmitter is used for short-distance (1-3km) transmitting high quality live image to the satellite communication bus then the satellite communication car transmit the A/V to the transmission station. Its convenient used for some far-away places where communication signal cannot directly cover it. Features High performance and cost-effectiveFull HD video(1920*1080i)Advanced OFDM Modulation Specification Central Frequency 320360Mhz,600860Mhz Modulation Standard COFDM FEC LDPC Modulation Mode QPSK Compressed Format H.264 Output Power ≤1000Mw Transmission Distance 2-3Km Channel Bandwidth 8MHz Video Data Rate ≥7.2Mbps Bit Error Rate ≤10-8 Video format Y,Pb,Pr Audio format Stereo Image definition Resolution:1920*1080i MTBF ≥10000 hours Operating Voltage DC12V Operating Temperature -30-+50 Operating Humidity Relative humidity 85% Dimension 180mm*110mm*88mm Weight 1.8 Kg
Delivery terms and packaging
Packaging Detail: One carton: 60cm*60cm*15cm4PCS portable transmitter. Delivery Detail: 2-3 weeks after payment
Port: CHENGDU
Payment term
Telegraphic transfer
Western Union
-
Payment Methods
We accept:
